Key features
- Adopting Sony STARVIS 2 & Pregius S Sensor
- Hardware ISP design without CPU/GPU Loading
- HDR ( High Dynamic Range ) Support
- DMA PCIe Design High-Bandwidth Capture, providing RGB444 video quality
- C-Mount Design offering flexibility for professional customers to use different lens combinations
Technical specifications
| System | |
|---|---|
| CPU | NVIDIA® Jetson Orin™ NX 8GB 6-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 1.5MB L2 + 4MB L3 NVIDIA® Jetson Orin™ NX 16GB 8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 2MB L2 + 4MB L3 |
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| AI Performance | NVIDIA® Jetson Orin™ NX 8GB 70 TOPS NVIDIA® Jetson Orin™ NX 16GB 100 TOPS |
| System Memory | NVIDIA® Jetson Orin™ NX 8GB 8GB LPDDR5 NVIDIA® Jetson Orin™ NX 16GB 16GB LPDDR5 |
| Interface | |
| Storage | Supports External NVMe 1×Micro SD Card Slot |
| Display Interface | 1×Mini DP1.4 |
| Ethernet | 1×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | M.2 1×M.2 2230 M Key PCIe Gen4×2 Slot 1×M.2 2230 E Key PCIe Gen4×1 Slot |
| USB | 1×USB3.2 Gen2 ( Type-C ) 1×USB3.2 Gen1 ( Type-A ) |
| Peripheral Communication | 14 Pin Header 1×USB2.0 4×GPIO 1×UART 1×I2C 8 Pin Phoenix Connector ( CON1 ) 1×GPIO 1×RS232 1×RS485 8 Pin Phoenix Connector ( CON2 ) 1×GPIO 2×I2C |
| Misc. Features | Firmware Upgradable |
