EDG6N0-S T5X
Jetson Thor edge-AI system with up to 2070 FP4 TFLOPS, HDMI 2.0, and DisplayPort 1.4
View product
Key features
- Powered by NVIDIA® Jetson Orin™ NX 16GB Super up to 157 TOPS
- Compact Size: 114.9mm×115mm
- 4×M.2, 8 Lanes MIPI CSI-2, and I2C / UART / GPIO / CAN Bus
- 2×USB3.2 Gen2, 2×USB2.0, 1×Nano SIM Card Slot
- 1×HDMI2.0
Technical specifications
| System | |
|---|---|
| SOM | NVIDIA Jetson Orin™ NX 16GB Super NVIDIA Jetson Orin™ NX 8GB Super |
| CPU | NVIDIA Jetson Thor™ 128 / 64GB 14-Core ARM Neoverse V3AE 64-bit CPU |
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| AI Performance | Up to 157 / 117 TOPS |
| System Memory | 16GB 128-bit LPDDR5 102.4GB/s 8GB 128-bit LPDDR5 102.4GB/s |
| Interface | |
| Storage | Supports External NVMe |
| Display Interface | 1×HDMI2.0 ( Up to 4K60 ) |
| Ethernet | 2×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | 1×M.2 2280 M Key PCIe Gen4×2 Slot 1×M.2 2280/3080 M Key PCIe Gen4×4 Slot, Support SSD or Video Capture Cards 1×M.2 2230 E Key PCIe Gen4×1+USB2.0 Slot, Support WiFi Module. 1×M.2 3042/3052 B Key USB3.2 Gen1 Slot, Support 5G/4G Wireless Module |
| USB | 2×USB3.2 Gen2 ( Type-A ) 1×USB3.2 Gen2 ( Type-C ) ( OTG ) 2×USB2.0 ( Type-A ) |
| MIPI | 8-Lane MIPI CSI-2 ( D-PHY 2.1, Support MIPI Camera, Capture Card ) |
| Audio | 1×Line In ( 3.5mm Phone Jack ) 1×Line Out ( 3.5mm Phone Jack ) |
| Peripheral Communication | 40 Pin Header 1×I2S 2×I2C 2×SPI 1×UART 3×GPIO 14 Pin Header 1×CAN Bus 1×UART with CTS/RTS 1×UART for Debug 1×Nano SIM Card Slot |
| Misc. Features | Firmware Upgradable TPM Module ( Optional ) |
