Best fit
- Industrial and embedded hosts with a documented MiniPCIe slot
- Compact SD-to-HD capture and encoding configurations
- Designs maintaining an established MiniPCIe platform
18 current catalog products
MiniPCIe capture cards for embedded integration
Use MiniPCIe when the target industrial or embedded host provides that expansion interface. MiniPCIe and M.2 are different mechanical and electrical formats, so the host documentation must decide between them.
Verify before selection
- That the host slot carries the interface required by the exact capture model
- Card dimensions, mounting, connector access, and enclosure clearance
- Signal, channel, resolution, driver, and operating-system support
18 current catalog products
Browse MiniPCIe capture-card series
Use the series summaries to choose a starting point, then search and shortlist individual models below.
11 PRODUCTS
ProAV MiniPCIe
ProAV MiniPCIe cards provide low-power full-HD capture for industrial and embedded hosts. Standard- and wide-temperature models support mobile, fanless, and transportation systems that use the MiniPCIe form factor.
- MiniCard ( PCIe×1 )
- 1×SDI
- 1920×1080p@60/50fps
- 1×HDMI, 1×SDI
- 1920×1080p@30/25fps
7 PRODUCTS
Pro H.26X MiniPCIe
Pro H.26X MiniPCIe cards provide onboard hardware compression for video from SD through full HD in embedded systems that use the standard MiniPCIe form factor.
- H.26X
- Minicard ( PCIe×1 )
- 1×SDI
- 8×CVBS
- 4×CVBS
- Minicard (PCIe x1)
PRODUCT FINDER
Find a model without scanning the whole catalog
Search by model, signal, or capability. Narrow by series, then add likely fits to your shortlist for side-by-side review.
18 matching products
Compare form factors
MiniPCIe is one host option
Return to the selection guide if the host or installation has not been decided.
PCIe
A strong fit for fixed hosts, higher channel counts, and systems where the capture card stays installed.
Review PCIeM.2
A compact internal option for embedded video and edge-AI designs where board space is limited.
Review M.2USB
An external option for laptops, portable kits, and systems where opening the host is impractical.
Review USBReview a MiniPCIe capture requirement
Send the host, input signals, channel count, resolution, operating system, and candidate models to the YUAN USA product team.
Send product requirements
