Best fit
- Desktop, workstation, and rackmount hosts
- Fixed broadcast, medical-video, industrial, and multi-camera systems
- Raw ProAV capture or on-card H.26X encoding
95 current catalog products
PCIe capture cards for fixed systems
Start with PCIe when the host is a desktop, workstation, or rackmount system with an available compatible slot. YUAN's PCIe catalog spans raw ProAV capture and models with hardware H.26X encoding.
Verify before selection
- Available PCIe slot size, generation, lane allocation, and physical clearance
- Signal type, channel count, resolution, frame rate, and loop-through needs
- Driver and SDK support for the exact model and host operating system
95 current catalog products
Browse PCIe capture-card series
Use the series summaries to choose a starting point, then search and shortlist individual models below.
64 PRODUCTS
ProAV PCIe
ProAV PCIe cards support multi-channel, multi-resolution capture with PCIe x1 through x8 options for standard workstations and multi-card systems. Model-specific capabilities include YUAN video processing and direct-to-GPU transfer for broadcast, vision, and medical-imaging integrations.
- PCIe×4 ( Gen2 )
- PCIe×1 ( Gen2 )
- 1920×1080p@60/50fps
- PCIe×1
- Single-Link HDMI 2.0
- 4096×2160p@60/50fps
31 PRODUCTS
Pro H.26X PCIe
Pro H.26X PCIe cards combine multi-channel video input with onboard H.26X hardware encoding. They support recording servers, broadcast systems, and video walls that require sustained capture and compression.
- H.26X
- PCIe×4 ( Gen2 )
- PCIe×1 ( Gen2 )
- PCIe×1 ( Gen1 )
- 4×SDI
- 8×SDI
PRODUCT FINDER
Find a model without scanning the whole catalog
Search by model, signal, or capability. Narrow by series, then add likely fits to your shortlist for side-by-side review.
95 matching products
Compare form factors
PCIe is one host option
Return to the selection guide if the host or installation has not been decided.
M.2
A compact internal option for embedded video and edge-AI designs where board space is limited.
Review M.2MiniPCIe
An internal embedded option for systems designed around MiniPCIe expansion rather than M.2.
Review MiniPCIeUSB
An external option for laptops, portable kits, and systems where opening the host is impractical.
Review USBReview a PCIe capture requirement
Send the host, input signals, channel count, resolution, operating system, and candidate models to the YUAN USA product team.
